Draco C60 Combi

C60 / 590
Dimensions(Including inlet/outlet pipes) – 730mm wide x 1040mm high x 1340mm long
Height above water level – 185mm
Capacity 13,000 Imp gallons per hour / 60,000 litres per hour (in gravity mode, pump fed less 25%)
Pond Volume – 8000 to 10000 UK gallons
Bio area – 590 litres @ fill volume of 66% equates to 400 litres of bio media
4 X 110mm Inlets / 3 x 110mm outlets and additional 2 x 63mm bypass outlets on either side (E.g. for showers)
FEATURES
Full length (utilises space under drum), diverted and downward flow, curve base biological chamber
Sloped and slotted base to drum chamber, to eliminate bio media clogging and particle buildup in this area
Large diameter and short length drum to maximise bio space and reduce water usage.
Split screen for easy access to the middle of the drum and easy bypassing of the unit
Quick release/change UV Resistant DPM Drum Seal
External short shaft, rim drive motor
Solid state water level sensors
